Introduction
At M2 Display, we believe in empowering our clients with knowledge. Understanding the core materials used in your custom displays is key to making informed decisions. This guide details the two most common wood-based substrates: MDF (Medium Density Fiberboard) and Plywood.
Material Comparison at a Glance
| Feature | MDF (Medium Density Fiberboard) | Plywood |
| Best Suited For | Aesthetics & Design Flexibility:
Perfect for visible surfaces requiring a flawless painted finish or complex curved shapes. |
Structural Integrity & Durability:
Ideal for internal frameworks, shelves, and areas where strength and moisture resistance are priorities. |
| Core Characteristics | • Smooth Surface: Ideal for a perfect paint finish. • High Machinability: Easily milled, engraved, and formed into curves. • Uniform Density: Consistent for precise manufacturing. |
• High Strength: Excellent load-bearing capacity, resists warping. • Good Moisture Resistance: More stable than MDF in humid conditions. • Superior Screw Holding: Fasteners hold securely. |
| Key Considerations | • Heavier than plywood. • Low Moisture Resistance: Not suitable for damp environments. • Softer Edges: Can be prone to chipping if not treated properly. |
• Rough Surface: Requires a surface layer (e.g., MDF or laminate) for a high-quality paint finish. • Limited Bendability: Difficult to create curved shapes. |
| Common Applications | • Cabinet doors and side panels. • Decorative elements and intricate profiles. • Any part requiring a high-gloss or matte paint finish. |
• Internal cabinet frames and structures. • Shelving and partitions. • Back panels and durable flooring for displays. |
| Cost Index | ⭐⭐ to ⭐⭐⭐ (Generally Cost-Effective) | ⭐⭐⭐ (Generally Cost-Effective) |
| Fire Rating | B1 Fire-Rated option available (Standard for shopping malls). | B1 Fire-Rated option available (Standard for shopping malls). |
How to Choose: A Simple Guide
- Choose MDF if… your priority is a sleek, painted finish or you have complex curves and designs. Best for indoor, dry environments like mall kiosks for jewelry, cosmetics, or fashion.
- Choose Plywood if… you need maximum strength and moisture resistance for structural parts, or for use in pop-up stores or areas with higher humidity.
- Choose the Hybrid Build if… you want the best of both worlds – which is what we recommend for over 90% of our projects.
Our Expert Recommendation: The Hybrid Build Principle
For the optimal balance of strength, durability, and a flawless aesthetic finish, we highly recommend our hybrid approach: “Plywood for the Core, MDF for the Surface.”
Why?
This method utilizes plywood for the internal skeleton of the cabinet, ensuring the structure is strong, light, and stable. A layer of 5mm MDF is then applied to all visible surfaces, providing the perfectly smooth base needed for a premium paint job.
The Result: You get a display that is built to last without compromising on a high-end, seamless appearance. This is our most proven and reliable construction technique.
FAQ
Q1: Which material is more environmentally friendly?
Both our standard MDF and Plywood meet E1 environmental standards (Formaldehyde emission ≤1.5mg/L), which is safe for indoor use. We can also source materials with higher certifications (like FSC) upon request.
Q2: My store is in a shopping mall. Are there special requirements?
Yes. Most mid-to-high-end malls require B1 fire-rated materials for both MDF and Plywood. This is our standard offering for such projects and a key part of our expertise in compliant store fitting.
Q3: Can I have a curved display made from plywood?
Generally, no. Plywood is not suitable for bending. For curved elements, MDF is the material of choice due to its ability to be routed and formed smoothly.
